AN6000 Series Optical Line Terminal Equipment Hardware Description
Table 7-11 Pinout and Wiring of the Straight-Through Cable
Local Connector Pin Wire Color
Opposite-End Connector Pin
1
White- / orange
1
2
Orange
2
3
White- / green
3
4 Blue 4
5 White- / blue 5
6 Green 6
7 White- / brown 7
8 Brown 8
Technical Specifications
Table 7-12 describes the technical specifications of the straight-through network
cable.
Table 7-12 Technical Specifications of the Straight-Through Cable
Item Specification
Cable model Cat5e network cable 4 × 2 × 24 AWG
Connector X1 / X2 RJ-45 connector
7.7 Time Cable
The time cable connects the equipment to an external time source to transfer time
signals.
Material Number
3695458
Structure
Figure 7-10 shows the appearance and structure of the time cable.
94
Version: B
