AN6000 Series Optical Line Terminal Equipment Hardware Description
2.1 Appearance and Structure
No. Name Function
①
Horizontal card slot Houses a fan unit.
②
Vertical card slots
Accommodate cards to implement various
functions of the equipment.
③
ESD protection earth ground fastener Connects with an ESD protection unit.
④
Mounting ears
Secure the subrack in a cabinet.
⑤
Fiber puller hanger Holds a fiber puller.
⑥
Subrack earth ground point
Connects with the subrack protection earth
ground cable.
2.2 Physical Parameters
Dimensions
Item
Specification
Dimensions of a subrack with mounting ears for 21-inch
cabinets (H × W × D)
Note 1
486 mm × 530 mm × 282 mm
Note 1: The AN6000-17 subrack is equipped with mounting ears for 21-inch cabinets by
default.
4
Version: B
