5 Cards
The normal working temperature for cards ranges from -40℃ to 65℃. The overall
power consumption is measured under the following conditions:
u Working voltage: -53.5 V DC
u Room temperature: 25℃ (static power consumption and typical power
consumption) or 55℃ (maximum power consumption)
u Static power consumption: All the broadband ports are deactivated.
u Typical power consumption: 50% of the broadband ports are concurrently
activated.
u Maximum power consumption: 100% of the broadband ports are concurrently
activated.
Note:
u The actual power consumption of these cards may deviate a little
from the values mentioned above due to different power modules
used and component discreteness.
u Generally for access equipment, power consumption is converted
into heat output. The unit of the former is W, and that of the later is
BTU/h. The two units are converted based on the formula 1 W ＝
3.412 BTU/h.
5.3 Core Switch Card
The core switch card aggregates, switches and controls traffic flow, processes
Layer 2 protocols, and manages the faults, performance and configuration of the
equipment.
5.3.1 HSCA
Basic Information
Refer to Card Overview for the number, power consumptions, maximum frame
length and weight of the card.
Version: B
29
