AN6000 Series Optical Line Terminal Equipment Hardware Description
Table 7-4 Technical Specifications of the Cabinet Protection Earth Ground Cable
Item
Specification
Cable model
ZR-RVV-105-1 × 16 mm
2
/ yellow- / green
X1 Bare wire
Terminal X2 Cord end terminal
7.3.3 Cabinet Protection Earth Ground Cable
The cabinet protection earth ground cable connects the earth ground point on the
top of a cabinet to the protection earth ground (PE) of the head of row cabinet, so as
to protect the cabinet.
Material Number
408000019
Structure
Figure 7-5 shows the appearance and structure of the cabinet protection earth
ground cable.
Figure 7-5 Cabinet Protection Earth Ground Cable
Technical Specifications
Table 7-5 describes the technical specifications of the cabinet protection earth
ground cable.
88
Version: B
