FiberHome AN6000 Series User Manual

7 Wires and Cables
Material Number
3695095
Structure
Figure 7-7 shows the appearance and structure of the subrack alarm cable.
Figure 7-7 Subrack Alarm Cable
Technical Specifications
Table 7-7 describes the technical specifications of the subrack alarm cable.
Table 7-7 Technical Specifications of the Subrack Alarm Cable
Item
Specification
Cable type
Cat5e network cable 4×2×24 AWG
Connector X1 / X2 RJ-45 connector
7.5 Fiber Jumper
Serving as the transmission carrier for optical signals, the fiber jumper is applied to
short-distance transmission of optical signals. It connects the optical interface of a
card to the ODF.
Structure
Table 7-8 shows the optical fiber connectors.
Version: B
91
