FiberHome AN6000 Series User Manual

1 Documentation Guide
Document Orientation
Hardware Description gives a detailed introduction to the hardware components of
the AN6000 Series. This manual is designed for readers who want to have a
detailed knowledge about the hardware of the equipment or need the hardware
information to guide them in O&M.
Intended Readers
u Marketing personnel
u Commissioning engineers
u Operation and maintenance engineers
Version Information
Version
Description
A Initial version.
B
Adds the GM8B, GFOA, KU1B and PXNA cards, laser signs,
and precautions for cabinet dust screens.
Content
Chapter Summary
The AN6000-17 Subrack
The AN6000-15 Subrack
The AN6000-7 Subrack
u Appearance and structure
u Physical parameters
u Slot configuration
u Fan unit
Cards
u Card structure and overview
u Interfaces and indicator LEDs on card panels
u Technical specifications and modules
u Functions
u Working principles
Modules
u Mappings between modules and cards
u Module types and specifications
Wires and Cables
u Cable overview
u Cable structure and specifications
Version: B
1
