AN6000 Series Optical Line Terminal Equipment Hardware Description
Structure
Figure 7-13 shows the appearance and structure of the dry contact cable.
Figure 7-13 Dry Contact Cable
Technical Specifications
Table 7-17 shows the technical specifications of the dry contact cable.
Table 7-17 Technical Specifications of the Dry Contact Cable
Item
Specification
Cable model Cat 5e network cable 4 × 2 × 24 AWG
Connector X1 RJ-45 connector
X2 Bare wire
7.11 Environment Monitoring Unit Connection
Cable
The environment monitoring unit connection cable connects the equipment's
environment monitoring serial port to an external environment monitoring device.
Model
409000158
98
Version: B
