AN6000 Series Optical Line Terminal Equipment Hardware Description
9.2.2 Specification
Functions and Specifications
Item
Specifications
Branch switch quantity Six (three active and three standby)
Standard working voltage
-48 V
Voltage range
-38 V to -60 V
Alarm signal processing
Receives alarm signals from the connected
equipment, provides audio alarms for the
signals, illuminates the cabinet-top
indicators, and outputs alarm signals to an
upper-layer device (such as the head of
row cabinet).
Environment
Operating temperature
-10℃ to 55℃
Storage temperature
-40℃ to 70℃
Relative humidity
≤ 95%
Atmospheric pressure
70 kPa to 106 kPa
Dimensions (W × H × D) (mm)
19 inch: 480 × 230 × 133
21 inch: 530 × 230 × 133
Weight (kg)
4.79
Specifications of Sub-Models
Sub-Model
Rated Current (A) for Branch
Switches
Mounting Mode
3000063-1FAR1A
32, 32, 32, 32, 32, 32
Mounted on the front vertical
mounting flanges of a 19-inch
cabinet
3000063-2FAR1A
32, 32, 32, 32, 32, 32
Mounted on the front vertical
mounting flanges of a 21-inch
cabinet
Note: The PDPs with the sub-models 1FA and 2FA use AC/DC circuit breakers.
Configuration Principles
u The current should be appropriate. A certain margin is required for capacity
expansion in future.
u The mounting mode of the PDP (3000063) should match with the cabinet type.
112
Version: B
