FiberHome AN6000 Series User Manual

AN6000 Series Optical Line Terminal Equipment Hardware Description
Item
Specification
Optical fiber
connector type
LC LC LC LC
Transmission
distance
0.55 km
Note 1
15 km 40 km 80 km
Receiving sensitivity
-17 dBm -23 dBm -23 dBm -25 dBm
Overload optical
power
0 dBm -3 dBm -3 dBm -3 dBm
Extinction ratio ＞ 9 dB 9.0 dB to 15 dB 9.0 dB to 15 dB 9.0 dB to 15 dB
Note 1: 50/125μm multi-mode optical fiber
GE Electrical Module
Item
Specification
Module code
1.25G-100m-TDM-SFP (10/100/1000BASE-T)
Module type
10/100/1000BASE-T
Encapsulation mode
SFP
Rate 1.25 Gbit/s
Connector type
RJ-45
Transmission distance 100 m
6.3.2 10GE Optical Module
Item
Specification
Module code
10G-0.3km-TDM-
SFP+ (10GBASE-
SR/SW)
10G-10km-TDM-SFP
+ (10GBASE-LR/LW)
10G-40km-TDM-SFP
+ (10GBASE-ER/EW)
10G-80km-TDM-SFP
+ (10GBASE-ZR/ZW)
Optical module
type
10GBASE-SR/SW 10GBASE-LR/LW 10GBASE-ER/EW 10GBASE-ZR/ZW
Wavelength range
840 nm to 860 nm 1260 nm to 1355 nm 1530 nm to 1565 nm 1530 nm to 1565 nm
Encapsulation
mode
SFP+ SFP+ SFP+ SFP+
Rate
9.953 Gbit/s to 11.09
Gbit/s
Note 1
1.229 Gbit/s to 10.
313 Gbit/s
Note 1
9.953 Gbit/s to 10.
313 Gbit/s
Note 1
9.953 Gbit/s to 11.3
Gbit/s
Output optical
power
-7.3 dBm to -1 dBm -8.2 dBm to 0.5 dBm -4.7 dBm to 4 dBm 0 dBm to 4 dBm
Optical fiber
connector type
LC LC LC LC
80
Version: B
