FiberHome AN6000 Series User Manual

7 Wires and Cables
7.1 Cable Overview
Cable Model
Applied to
Subrack DC power cables for
the PDP850A (3000064)
-48 V power cable: 408000363
The PIBA card connecting to the
PDP850A (3000064)
0 V power cable: 408000364
Subrack DC power cables for
the PDP260B (3000063) /
PDP296B (3000068)
-48 V power cable: 408000436 The PIBA card connecting to the
PDP260B (3000063) or PDP296B
(3000068)
0 V power cable: 408000437
Subrack protection earth
ground cable
3696084
AN6000-7, AN6000-15 and
AN6000-17 subracks
Cabinet protection earth
ground cables
16 mm
2
protection earth ground cable:
3696100
PDP850A (3000064)
25 mm
2
protection earth ground cable:
408000019
PDP260B (3000063), PDP850A
(3000064) and PDP296B
(3000068)
Alarm cable for the head of
row cabinet
3695135
PDP850A (3000064) and
PDP296B (3000068)
Subrack alarm cable 3695095 CIOA card
Fiber jumpers
SC/PC optical fiber jumper: OFC-SC/PC-
SC/PC-S-20
GPOA, EX8A, EXOA, GX8A,
GM8A, GM8B, GMOA, GNOA and
GFOA cards
LC/PC optical fiber jumper: OFC-LC/PC-
LC/PC-S-20
HSCA, HU8A, KU1B and PXNA
cards
Network cable 3695095
HSCA, HU8A, KU1B and PXNA
cards
Time cable 3695458 CIOA card
Clock cable 3695187 CIOA card
Serial port line
3695341 HSCA card
Dry contact cable
3695452 CIOA card
Environment monitoring unit
connection cable
409000158 HSCA card
7.2 Power Cable
This section introduces the applications, model numbers, structures and technical
specifications of the power cables.
