AN6000 Series Optical Line Terminal Equipment Hardware Description
Item
Specification
Alarm reporting of the
lightning protection
module
Outputs lightning protection failure alarm signals
(which will be reported to the EMS via the
equipment connected to the PDP) when the
lightning protection module fails.
DC lightning
protection
Differential mode
protection
2 kV
Common mode
protection
4 kV
Environment
Operating temperature
-10℃ to 55℃
Storage temperature
-40℃ to 70℃
Relative humidity
≤ 95%
Atmospheric pressure
70 kPa to 106 kPa
Dimensions (D × W × H) (mm)
19 inch: 483 × 146 × 150
21 inch: 530 × 146 × 150
Weight (kg)
4.815
Specifications of Sub-Models
Sub-Model
Rated Current (A) for Branch Switches Mounting Mode
3000064-1FHR1AA
63, 63, 63, 63, 63, 63, 63, 63
Mounted on the front vertical mounting
flanges of a 19-inch cabinet
3000064-2FHR1AA
63, 63, 63, 63, 63, 63, 63, 63
Mounted on the front vertical mounting
flanges of a 21-inch cabinet
Configuration Principles
u The current should be appropriate. A certain margin is required for capacity
expansion in future.
u The mounting mode of the PDP (3000034) should match the cabinet type.
Standard Compliance
Item Standard
Electromagnetic
compatibility (EMC)
Electromagnetic
interference (EMI)
Radiated emission (RE) Complies with EN55022 Class B.
Conducted emission (CE) Complies with EN55022 Class B.
Electrostatic discharge (ESD) Complies with IEC61000-4-2.
Electromagnetic
susceptibility (EMS)
Radiated susceptibility
(RS)
Complies with IEC61000-4-3.
118
Version: B
