9 PDPs
Item
Specifications
Alarm function
Alarm signal processing
Receives alarm signals from the connected
equipment, provides audio alarms for the
signals, illuminates the cabinet-top indicators,
and outputs alarm signals to an upper-layer
device (such as the head of row cabinet).
Alarm reporting of the
lightning protection
module
Outputs lightning protection failure alarm signals
(which will be reported to the EMS via the
equipment connected to the PDP) when the
lightning protection module fails.
DC lightning
protection
Differential mode
protection
2 kV
Common mode protection
4 kV
Environment
Operating temperature
-10℃ to 55℃
Storage temperature
-40℃ to 70℃
Relative humidity
≤ 95%
Atmospheric pressure
70 kPa to 106 kPa
Dimensions (D × W × H) (mm)
19 inch: 483 × 186 × 100
21 inch: 530 × 176 × 100
Weight (kg)
4.2
Specifications of Sub-Models
Sub-Model
Branch Switch
Quantity
Input Features
Rated Current
(A) for Branch
Switches
Mounting Mode
3000068-1FAR1A
Six (three active
and three
standby)
Providing two
independent
channels (one
active and one
standby) of power
supplies with
current up to 96 A
32, 32, 32, 32, 32,
32
Mounted on the front vertical
mounting flanges of a 19-inch
cabinet
3000068-2FAR1A
Mounted on the front vertical
mounting flanges of a 21-inch
cabinet
Configuration Principles
u The current should be appropriate. A certain margin is required for capacity
expansion in future.
u The mounting mode of the PDP (3000068) should match with the cabinet type.
Version: B
125
