9 PDPs
Figure 9-14 Protection Earth Ground Cable for the PDP (3000068)
Connection
Table 9-12 Connections of the PDP (3000068) Protection Earth Ground Cable
Cable Connector Connected to
1. Uninsulated copper cord
end terminal
Inner PE connector of the PDP
2. Pre-insulation terminal
Ground terminal of the cabinet protection earth ground
3. Bare wire
Welded onto the PCB earth ground point before delivery
Version: B
131
