FiberHome AN6000 Series User Manual

4 The AN6000-7 Subrack
Dimensions
Item Specification
Dimensions of a subrack with mounting ears for 19-
inch cabinets (H × W × D)
Note 1
266 mm × 480 mm × 253.8 mm
(excluding the fiber passage unit)
Dimensions of a subrack with mounting ears for 21-
inch cabinets (H × W × D)
266 mm × 530mm × 253.8 mm
(excluding the fiber passage unit)
Note 1: The AN6000-7 subrack is equipped with mounting ears for 19-inch cabinets by default.
Weight
Item Specification
Weight of an empty subrack (excluding the fan unit) 8.5 kg
Weight of an empty subrack (including the fan unit) 10.7 kg
Operating Environment
Item
Specification
Operating temperature
-40℃ to 65℃
Operating relative humidity 5% to 95% (non-condensing)
Storage temperature
-40℃ to 70℃
Relative humidity for storage 5% to 95% (non-condensing)
Power Supply Parameters
Item Specification
Maximum input current
37.5 A
Power supply mode
DC (two channels of power supplies forming
redundancy protection)
Working voltage range
-38.4 V to -57.6 V
Rated voltage
-48 V
Overall Power Consumption
The overall power consumption is measured under the following conditions:
u Working voltage: -53.5 V DC
u Room temperature: 25℃ (static power consumption and typical power
consumption) or 55℃ (maximum power consumption)
Version: B
19
