AN6000 Series Optical Line Terminal Equipment Hardware Description
Table 5-15 Indicator LEDs (Continued)
Identifier
Meaning
Color Status
Description
Blinking
quickly
The card is receiving a
configuration command from the
core switch card or the
communication between the active
and standby cards is being set up.
OFF
The card is not powered on
normally or is reset abnormally.
ALM
Alarm indicator
LED
Red
ON
The card has an urgent alarm.
OFF
The card has no urgent alarms.
LINK 1 to 8
Port status
indicator LED
Green
ON
The ONU under the PON port is
registered and authorized.
OFF
No ONU under the PON port is
registered or authorized.
Technical Specifications
See Comparison Between 10G EPON Interface Cards for technical specifications of
the card.
Modules
Module Type
Module Code
10G EPON optical module
10/1.25G-20km-10G EPON OLT symmetric-XFP (10G
BASE-PR30)
Note 1: 10G EPON Optical Module describes the module specifications.
Functions
For functions of the card, see Comparison Between 10G EPON Interface Cards.
46
Version: B
