AN6000 Series Optical Line Terminal Equipment Hardware Description
Table 5-18 Interfaces
Identifier
Meaning Description
1 to 8
XG-PON ports
Connect to ONUs via an ODN.
Table 5-19 Indicator LEDs
Identifier
Meaning
Color Status
Description
ACT
Working
indicator
LED
Green
ON
The card is working normally.
Blinking
slowly
The card is being initialized.
Blinking
quickly
The card is receiving a configuration
command from the core switch card or the
communication between the active and
standby cards is being set up.
OFF
The card is not powered on normally or is
reset abnormally.
ALM
Alarm
indicator
LED
Red
ON
The card has an urgent alarm.
OFF
The card has no urgent alarms.
LINK 1 to 8
Port
status
indicator
LED
Green
ON
The ONU under the PON port is registered
and authorized.
OFF
No ONU under the PON port is registered
or authorized.
Technical Specifications
Item
Specification
Port quantity
8
Forwarding performance
80 Gbit/s
Rate mode
Asymmetric rate mode
Port rate
u Uplink: 2.488 Gbit/s
u Downlink: 9.953 Gbit/s
Maximum split ratio
1:256
Maximum number of T-CONTs supported by
each PON port
2048
Maximum number of MAC addresses 65536
Maximum differential fiber distance (maximum
difference of ONU-to-PON port distance between
two ONUs under the same PON port)
40 km
Supported ONU types 10G / 2.5G (downlink rate / uplink rate)
50
Version: B
