FiberHome AN6000 Series User Manual

AN6000 Series Optical Line Terminal Equipment Hardware Description
Table 5-31 Indicator LEDs
Identifier
Meaning
Color Status
Description
ACT
Working
indicator
LED
Green
ON
The card is working normally.
Blinking
slowly
The card is being initialized.
Blinking
quickly
The card is receiving a configuration
command from the core switch card or the
communication between the active and
standby cards is being set up.
OFF
The card is not powered on normally or is
reset abnormally.
ALM
Alarm
indicator
LED
Red
ON
The card has an urgent alarm.
OFF
The card has no urgent alarms.
1 to 16
Port status
indicator
LED
Green
ON
The ONU under the PON port is registered
and authorized.
OFF
No ONU under the PON port is registered
or authorized.
Technical Specifications
See Comparison Between PON Combo Interface Cards for technical specifications
of the card.
Matching Module
Module Type
Module Code
GPON optical module 2.5/1.25G-20km-GPON OLT-SFP (CLASS C+)
GPON & XG-PON Combo
optical module
10/2.5G: 2.5/1.25G-20km-XG-PON: GPON OLT-SFP+ (C+
ODN CLASS)
GPON & XGS-PON Combo
optical module
10/10G: 10/2.5G: 2.5/1.25G-20km-XGS-PON: XG-PON:
GPON OLT-SFP+ (C+ ODN CLASS)
Note 1: GPON Optical Module and Combo PON Optical Module describe the module
specifications.
Function
For functions of the card, see Comparison Between PON Combo Interface Cards.
66
Version: B
