AN6000 Series Optical Line Terminal Equipment Hardware Description
Table 5-32 Interfaces
Identifier
Meaning Description
1 to 24
10GE / GE ports
Connect to an IP network.
Table 5-33 Description
Identifier
Meaning
Color Status
Description
ACT
Working
indicator LED
Green
ON
The card is functioning
properly.
Blinking slowly The card is being initialized.
Blinking
quickly
The card is receiving a
configuration command from
the core switch card or the
communication between the
active and standby cards is
being set up.
OFF
The card is not powered on or
is reset unexpectedly.
ALM
Alarm
indicator LED
Red
ON
The card has alarms, or the
communication between the
active and standby cards is
interrupted.
OFF The card has no alarms.
1 to 24
Port status
indicator LED
Green
ON
A link is set up at the port.
Blinking
The port is transmitting or
receiving data.
OFF
No device is connected to the
port.
Technical Specifications
Item
Specification
Network standards
IEEE802.1ag, IEEE802.3x, IEEE802.3z, IEEE802.3ak, IEEE802.
3ap, IEEE802.3ba, Y.1731
Operating modes
1Gbit/s, 10Gbit/s
Modules
Item
Specification
GE optical module 1.25G-15km-TDM-SFP (1000BASE-LX)
68
Version: B
