FiberHome AN6000 Series User Manual

AN6000 Series Optical Line Terminal Equipment Hardware Description
Item
Specification
XG-PON
Tx: 1577 nm (1575 nm to 1580 nm)
Rx: 1270 nm (1260 nm to 1280 nm)
XG-PON
Tx: 1577 nm (1575 nm to
1580 nm)
Rx: 1270 nm (1260 nm to
1280 nm)
Encapsulation mode
XFP SFP+ XFP
Rate
GPON
Tx: 2.488 Gbit/s
Rx: 1.244 Gbit/s
GPON
Tx: 2.488 Gbit/s
Rx: 1.244 Gbit/s
XG-PON
Tx: 9.953 Gbit/s
Rx: 2.488 Gbit/s
XG-PON
Tx: 9.953 Gbit/s
Rx: 2.488 Gbit/s
Output optical power
GPON: 3 to 7 dBm GPON: 3 to 8 dBm
XG-PON: 5 to 9 dBm XG-PON: 4 to 8 dBm
Optical fiber connector
type
SC/PC or SC/UPC SC/PC or SC/UPC
Transmission distance 20 km 20 km
Receiving sensitivity
GPON: -32 dBm GPON: -32 dBm
XG-PON: -30.5 dBm XG-PON: -29.5 dBm
Overload optical power
GPON: -12 dBm GPON: -12 dBm
XG-PON: -10 dBm XG-PON: -9 dBm
Extinction ratio
GPON: ＞ 8.2 dB GPON: ＞ 8.2 dB
XG-PON: ＞ 8.2 dB XG-PON: ＞ 8.2 dB
Note 1: C+ ODN CLASS corresponds to Class D2 in China Telecom standards.
GPON & XGS-PON Combo Optical Module
Item
Specification
Module code
10/10G: 10/2.5G: 2.5/1.25G-20km-XGS-PON: XG-PON: GPON OLT-SFP+ (C+
ODN CLASS)
Optical module type
C+ ODN CLASS
Wavelength range
GPON
Tx: 1490 nm (1480 nm to 1500 nm)
Rx: 1310 nm (1290 nm to 1330 nm)
XGS-PON
Tx: 1577 nm (1575 nm to 1580 nm)
Rx: 1270 nm (1260 nm to 1280 nm)
Encapsulation mode
SFP+
78
Version: B
