Chapter 5: System Software
5-7
Software Functions List
There are six function groups, each corresponding to a key on the
control panel. In the following table:
• A function denoted with the (*) symbol indicates it is available
in the Operate Mode.
• A function denoted with the (°) symbol indicates it is available
in the Calibrate Mode only.
• A function denoted with the (‡) symbol indicates it is available
only when switch S1-5 is open in the Calibrate Mode.
• A function denoted with a (∞) symbol indicates it is available
only when switch S1-6 is open in the Calibrate Mode.
Function Group Function Name Parameter Default
Fill Level Key 1
* X-ray Status On/Off On
* Autoshutter Status Auto/On Auto
* Underfill Status On/Off Off
*Overfill Status On/Off Off
* X-ray Counts 0-65,000 Pulses:
Updating Constantly
Updating Rejects Only
Updating Constantly
* Target Head Height 0-999 Ticks 500 Ticks
° X-ray Threshold 0-5,000 Counts 750 Counts
° Looktime Gate 1 -120 ms 17 ms
° Fill Level Optimization Execute
° Learn Target Head Height Execute
° Dyn. Reject Pt. Test Execute
° Dyn. Prod. Good Test Execute
° Review Fill Level Test Execute
Finishing Key 2
* Bulged End Status On /Off Off
* Missing Lid Status On /Off Off
* Down Can Status On /Off Off
* Dia. Missing Lid Status On /Off Off
* External Reject Status On/Off Off
1
2
