Controller Board LED Locations
The FT-70’s Controller Board contains 1 bank of 11 LEDs. The
LEDs are divided into logical sections and banks which are
configured by dip switches S2-7 and S2-8.
Figure 10-2. Locating the LEDs on the Controller Board.
LEDs:
1
2
3
4
5
6
7
8
9
10
11
