FT-70 Fill Level Inspector Service Manual
8-26
Main Processor Card Troubleshooting
If the main processor card fails a total system shutdown will occur.
Check to be sure that all power sources are functioning correctly. If
they are functioning correctly, replace the processor card.
Figure 8-7. The Processor Card.
LED 12
U25
U26
Industrial Dynamics Company, Ltd. © 40256-0600
