Chapter 10: Controller Board Dip Switches and LEDs
10-3
Controller Board Switch Locations
The FT-70’s Controller Board contains 2 Dip Switch Packs (S1 and
S2) which contain 8 switches each. The Controller Board also
contains 3 Slide Switches (S3, S11, S13).
Figure 10-1. Switch locations on the Controller Board.
S2
S13
S1
S3
S11
Industrial Dynamics Company, Ltd. © Form 40256-0600
