Chapter 3: Installing the FT-70
3-9
2. Cut the vertical support pipe to the calculated length (L
p
),
removing the excess from the end that is not flanged.
Figure 3-4. Removing the excess from the vertical support pipe.
3. Assemble the mounting base tripod. Leave the bolts loose
enough to slide the vertical support pipe inside.
Figure 3-5. Assembling the mounting base tripod.
1
2
No. Description
1 Remove excess from this end.
2 Flanged end
Industrial Dynamics Company, Ltd. © Form 40256-0600
