Chapter 4: Configuring the FT-70 for Operation
4-13
Note
Bulged end detection is only available when the containers are
oriented in top-up position.
1. Center a properly filled and sealed production container under
the downstream sensor mounting bracket.
2. Loosen the downstream sensor mounting bracket adjustment
knob and adjust the sensor so that it is 1mm above the
container lid.
Note
If you do not have enough adjustment range to position the sensor
correctly, reposition the sensor receiver and emitter in the bracket
by moving it up or down enough hole positions to give you the
range you need.
3. Tighten the adjustment knob to secure the positioning.
4. If you will not be performing further alignment procedures,
turn on the Safety Interlock Switch to reactivte the X-ray
Generator. See Chapter 5: The Safety Interlock Switch.
Industrial Dynamics Company, Ltd. © Form 40256-0600
