8. Generator Tables
8.1 Cable cross section
Fig. 8.1.0-1: Kabelquerschnitte/Cable cross sectiion
8.2 Diameter of conduits
Fig. 8.2-1: Diameter of conduits
8.3 Technical Data
Fig. 8.3-1: Technical Data generator
Länge/length 1 - 3 m 4 - 6 m 7 - 10 m 11 - 15 m 16 - 20 m
2,5 mm²
4 mm²
6mm²
10mm²
16 mm² 70 A 63 A 55 A 48 A 42 A
25mm² 112 A 100 A 88 A 75 A 63 A
35mm² 145 A 130 110 100 A 90 A
50mm² 225 A 200 A 175 A 150 A 125 A
70mm² 275 A 250 A 225 A 195 A 170 A
95mm² 340 A 300 A 280 A 260 A 220 A
Generator type Ø Cooling water pipe Ø Exhaust hose
[mm]
Ø Fuel hose
Fresh water
[mm]
Raw water
[mm]
Supply
[mm]
Return
[mm]
Panda 5000i PMS 20 20 30 8 8
Panda 5000i PMS Panda 5000i PMS with Tier 4
Type EA 300 EA330
Govenour Servo Servo
Cylinder 1 1
Bore 75mm 77
Stroke 70mm 70
Stroke volume 309cm
3
325cm³
max. Power (DIN 6270-NB) at 3000rpm 5,1kW 5,15kW
Rated speed 3000rpm 3000
Idle speed running
a
a. progressive speed by VCS
2900rpm 2900
Valve clearance (engine cold) 0,16 - 0,20mm 0,16-0,20
Cylinder head torque 58,8 - 63,7Nm 58,8 - 63,7Nm
Lubrication oil capacity 1,3l 1,3l
Fuel consumption
b
b. 0,35l/kW electrical power, the randomized values between 30% and 80% of the nominal power
approx. 0,42 - 1,12 l approx. 0,42 - 1,12 l
