Inverter Panda PMGi 5000
PGMi 5000_eng.fm Kapitel 10: Inverter Panda PMGi 5000 - Seite 131
Fischer Panda Datenblatt / Datasheet
10.9.3 PMGi out
Voltage
10.10PMGi protections
10.10.1 Overload - switch point
10.10.2 Short circiut
To operate the short circiut protection a fuse must be put in series with the live wire. The minimum requested feature
for this fuse are the following.
Note!
The electrical Data refer to the system running in accordance with all the limits defined in the
„General Specification“ table.
Nominal Voltage NOV
AC
230 VAC +/- 5% without load
120 VAC +/- 5% without load
Regulation R 5%
Stability (short term (30sec)) D
s
5%
Stability (Long term (4h)) D
l
5%
Voltage offset V
offset
+-5V -20°C bis +40°C
Current Current
Nominal
@230V
eff.
see type plate
Current
Maximum
@230V
eff.
see type plate
Power Nominal power see type plate
Long term see type plate
Frequency Nominal Frequency see type plate
Regulation 4%
Stability (short term (30sec)) 3%
Stability (Long term (4h)) 3%
Output type Max. current Comments
230VAC 30,0A +/- 0.5A When protection takes place the engine must be switched off and all apliances
detached
Rated current 1.2 1.5 2.75 4.0 10.0
26A >1h <30min 5ms to 150ms 2ms to 15ms <2ms
