Inverter Panda PMGi 5000
Seite 130 - Kapitel 10: Inverter Panda PMGi 5000 PGMi 5000_eng.fm
Fischer Panda Datenblatt / Datasheet
10.8 Installation of the PMGi
The PMGi must be mounted vertical, with the electrical connection down. So you can read the writing on the PMGi.
The surface where the PMGi is mounted should be smoothed and support the heat transfer. The Air holes and Air
grille must be not covered and enough cooling air must be pleasant at any time for the PMGi.
To mount the PMGi use the four fixing holes diameter 6,5mm.
Note!
See the safety instruction in your Generator and iControl
Manual.
The rules of the respective regional authority must be adhered to. Only an electrician may carry out installation of the
electrical connections for safety reasons.
10.8.1 Electrical connection.
Only special trained persons are allowed to make the electrical connection.
When an extension cable is required, be sure to use a though rubber sheated flexible and fireproof cable. Limit
length of extension cables depends on the voltage drop along the cable. This drop must be less than 2,5% value of
the nominal output voltage.
Pay attention to the right pin assignment. See “Socket pins of the PMGi 5000” on page 127.
10.9 Technical Data
10.9.1 General Data
PMGi is part of the Panda i-series generator. It´s not allowed to be used with other generators or aplications.
10.9.2 Generator Spezifikation
Storage temperature PMGi -20°C to +55°C
Working temperature PMGi Minimum: -20°C
Maximum: +40°C
Maximale internel temperature of the PMGi:
+60°C
PMG Generator out 3 phase
Voltage Phase minimum 250V AC Maximum 550V AC
Frequency minimum 250 Hz Maximum 650 Hz
