Fischer Panda 5000i PMS - Oil Circuit and Monitoring Systems; Oil Circuit Components; Operating Surveillance Sensors

Panda 5000i PMS generator
Seite/Page 50 Panda_5000i_PMS_eng.R01 - Kapitel/Chapter 4: Panda 5000i PMS generator 9.12.10
4.3.7 Components of the Oil Circuit
Fig. 4.3.7-1: Components of the Oil Circuit
4.3.8 Sensors and switches for operating surveillance
Fig. 4.3.8-1: Thermo.switch at engine Thermo-switch at engine
The thermo-switch at the engine is used for monitoring the
engine temperature.
oil filler cap
engine
Kubota EA300
oil strainer
oil dipstick
oil
pressure
switch
oil drain hose
iControl electronic board
operator control
oil in
oil
out
