Maintenance Instructions
9.12.10 Panda_5000i_PMS_eng.R01 - Kapitel/Chapter 6: Maintenance Instructions Seite/Page 87
Fig. 6.6-1: Oil filling cap
2. Loosen oil filling cap
Unscrew the oil filling cap. This is necessary, because
otherwise a vacuum will form and the oil can not comple-
tely drain off.
Sample picture
Fig. 6.6-2: Oil drain hose
3. Open oil drain screw.
Unsrew the oil drain screw by means of the open-ended
wrench from the oil drain hose (rotating direction left).
Use a second open-ended wrench to lock. Make sure to
do this over the container.
Use spanner size 17mm.
4. Discharge used oil.
Let the entire amount of oil drain out of the engine. This can take several minutes.
Fig. 6.6-3: Oil filter
5.
Remove used oil filter / clean oil screen
Release the oil filter by turning the filter wrench counter-
clockwise. The filter might be full of oil. Make sure to not
spill anything and avoid skin contact.
Sample picture
