4.6.4.2 <NM> command
The
<NM> command displays the ITU-T G.991.2 Noise Margin performance parameters.
(The maximum possible increase in the noise margin at which the BER is expected to be less
that 10
-7
.)
The action of the <NM> command terminates by entering any other command or by pressing
“enter”.
CO_FMM>NM
Channel: DSL1 DSL2 DSL3 DSL4
xDSL NM: 10.5 11.5 10.5 10.0 dB
xDSL NM: 10.5 11.5 10.5 10.0 dB
xDSL NM: 10.5 11.5 10.5 10.0 dB
↵
CO_FMM>
The number of columns is equal to the number of xDSL channels of the device. Normal quality
of data transmission is possible only for NM≥8 dB.
4.6.4.3 <STATUS> command
The <STATUS> command displays the actual status of the xDSL transceiver.
CO_04_FMM>STATUS
----------------------------------------------------------------------------
Status : DSL1 DSL2 DSL3 DSL4
----------------------------------------------------------------------------
I/F mode : CP CO CP CO
SYNC : 1 1 1 1
SEGD : 1 1 1 1
Power backoff : 0.0 0.0 0.0 0.0 dbm
Far end power backoff : 1.0 1.0 1.0 1.0 dbm
Loop attenuation : 14.0 14.0 14.0 14.0 dB
NMR : 11.5 11.5 11.5 11.5 dB
Bitrate : 4104 4104 4104 4104 kbit/s
SRU # : 0 0 0 0
Active sync. source : E1-1 E1-2 E1-3 E1-4
----------------------------------------------------------------------------
Temperature : 37.375 C
Power mode : P0 (CPU@50MHz)
----------------------------------------------------------------------------
CO_04_FMM>
Option: T – update the table continuously.
Option: L – show the DSL and Link parameters.
Table 4.2 «<STATUS> - definitions».
Parameter Value Description
I/F mode CO
CP
The interface is in the Master mode
The interface is in the Slave mode
SYNC 1
- (0)
Synchronization in the xDSL line is established.
Synchronization in the xDSL line is absent.
SEGD 1
0
-
Data, transmitted over the xDSL line, are valid
Data, transmitted over the xDSL line, are not valid
Data are not received
