User Manual NTU Orion 2
82
4.6.5.4 <MASTER ON/OFF N> command
The <MASTER ON/OFF N> activates/deactivates the «MASTER» mode on the interface with
the number N.
The <MASTER ON> activates the MASTER mode. The <MASTER OFF> command activates
the SLAVE mode.
For single-channel modems, the command is used without the number of the xDSL channel.
Note:
1. In the data transmission systems one device should be configured as a Master
device, while the other – as a Slave device.
2. For regenerators, the parameter N is used to select the interface DSL1/DSL2 (the
ON/OFF is not used).
4.6.5.5 <EXT ON/OFF N> command
The EXT ON/OFF N command activates/deactivates the standard and the extended G.SHDSL
mode on the interface with the number N.
Note:
The EXT ON feature needs a special LICENSE that has to be ordered together with the unit.
In extended mode higher data rates and line codes (PAM4, PAM8, PAM32, PAM64, PAM128)
are available.
Standard mode
Command Channel Coding Min Baserate Max Baserate
PAM 16 PAM 16 3 60
PAM 32 PAM 32 12 89
Extended mode
PAM 4 PAM 4 2 35
PAM 8 PAM 8 3 71
PAM 16 PAM 16 1 119 (106)
PAM 32 PAM 32 1 159 (142)
PAM 64 PAM 64 2 199 (178)
PAM 128 PAM 128 4 238 (not available)
Please NOTE:
The values in the braces are for Model that have no ++ in the Hardware Version (HW 1.8++)
V52 & V53 models do not support PAM128
