Remote Commands
Summary of Commands and Queries
6
6-27
OUT
Overlapped CoupledIEEE-488 RS-232 Sequential
xx xx x
Sets the output of the 5500A Calibrator and establishes a new reference point for the
error mode. If only one amplitude is supplied, the 5500A Calibrator sources a single
output. If two amplitudes are supplied, the 5500A Calibrator sources two outputs. The
second amplitude will be sourced at the AUX terminals for dual voltage outputs. If the
frequency is not supplied, the 5500A Calibrator will use the frequency that is presently
in use.
To source or measure a temperature, select the desired sensor and sensor parameters
first. (See the TSENS_TYPE, RTD_*, and TC_* commands.)
To source a signal using the 5500A-SC option, refer to the SCOPE command in
Chapter 8.
If you change the frequency of an ac function and the harmonic output is not explicitly
set at the same time with the HARMONIC command, the harmonic will be set to 1.
Use multipliers e.g., k, M, µ with the OUT command, as desired.
Parameters: <value> V Volts dc or update volts ac
<value> DBM Volts ac dBm update
<value> V, <value> Hz Volts ac or volts dc with 0 Hz
<value> DBM, <value> Hz Volts ac in dBm
<value> A Current dc or update current ac
<value> A, <value> Hz Current ac
<value> OHM Resistance
<value> F Capacitance
<value> CEL Temperature (Celsius)
<value> FAR Temperature (Fahrenheit)
<value> HZ Update frequency
<value> V, <value> A Power dc or update power ac
<value> DBM, <value> A Power ac in dBm update
<value> V, <value> A, <value> HZ Power ac
<value> DBM, <value> A, <value> HZ Power ac in dBm
<value> V, <value> V Dual volts dc or update dual ac
<value> DBM, <value> DBM Dual volts ac in dBm update
<value> V, <value> V, <value> HZ Dual volts ac in volts
<value> DBM, <value> DBM, <value> HZ Dual volts ac in dBm
<value> For single output, changes
amplitude keeping unit and
frequency the same.
Examples: OUT 15.2 V (volts; 15.2 V @ same frequency)
OUT 20 DBM (volts; 20 dBm @ same frequency)
OUT 10 V, 60 Hz (volts ac; 10 V @ 60 Hz)
OUT 10 DBM, 50 HZ (volts ac; 10 dBm @ 50 Hz)
OUT 1.2 MA (current; 1.2 mA @ same frequency)
OUT 1 A, 400 HZ (current ac; 1 A @ 400 Hz)
OUT 1 KOHM (ohms; 1 kΩ)
OUT 1 UF (capacitance; 1µF)
OUT 100 CEL (temperature; 100 °C)
OUT -32 FAR (temperature; -32°F)
OUT 60 HZ (frequency update; 60 Hz)
