Remote Operation
Commands 5
5-41
Table 5-2. Commands (continued)
UNCERT?
Description Sequential command.
Returns the calculated maximum uncertainty of the calibrator’s output according to the
selected calibration interval. (The same as pressing s from the front panel.)
Parameter None
Response
1. (Float) Uncertainty of the calibrator’s output (-1.0 if no specification is available)
2. (String Units for response 1 (PPM, PCT, V, A, OHM, etc.)
3. (Integer) The specification interval in days.
VOUT?
Description Sequential command.
Returns the output amplitude expressed in volts if the currently selected units are dBm.
Parameter None
Response
1. (Float) Output amplitude
2. (String) V, A, OHM; units for response 1
3. (Float) Frequency
Example: Assuming a value of 10 dBm, 10 kHz is currently active on the main output terminals,
VOUT? returns: "2.4494897E+00,V,1.0000E+04"
*WAI
Description Sequential command.
(Wait-to-Continue.) This command prevents further remote commands from being executed
until all previous remote commands have been executed. (See also *OPC.)
Parameter None
Example: If you had sent an OUT command, you can cause the calibrator to wait until the output has
settled before continuing on to the next command by following OUT with a *WAI command.
This is useful because OUT is an overlapped command, which means the calibrator would
normally go on to process other commands before completing the OUT command.
WBAND
Description Overlapped command, ignored if not in remote.
Activates or deactivates output from the Wideband AC Module (Option 5700A-03). This has
the same action as pressing w from the front panel during local operation.
Parameter ON or OFF
