Fluke 5700A Series II User Manual

5700A/5720A Series II
Operators Manual
5-42
Table 5-3. Serial Remote Control Commands
LOCAL
Description Sequential command.
Enables the local state. This command duplicates the IEEE-488-GTL (Go to Local)
message.
Parameter None
LOCKOUT
Description Sequential command.
Enables the local lockout state. This command duplicates the IEEE-488 LLO (Local
Lookout) message.
Parameter None
REMOTE
Description Sequential command.
Enables the remote state. This command duplicates the IEEE-488 REN (Remote Enable)
message.
Parameter None
Table 5-4. Range Identifiers for Remote Commands
Function Ranges
DC Voltage
DC220MV DC22V DC1100V DC2_2V DC220V
DC5205V DC11V
DC Current
DC220UA DC 220A DC5220A DC2_2MA DC2_2A
DC5725A DC22MA
AC Voltage
AC2_2MV AC22V AC5205V AC22MV AC220V
AC5215V AC220MV AC1100V AC5725V AC2_2V
AC Current
AC220UA AC220MA AC5220A AC2_2MA AC2_2A
AC5725A AC22MA
Resistance
OHM0 OHM190 OHM190K OHM1 OHM1K
OHM1M OHM1_9 OHM19K OHM1_9M OHM10
OHM10K OHM10M OHM19 OHM19K OHM19M
OHM100 OHM100K OHM100M
Wideband
WB1_1MV WB33MV WB1_1V WB3_3MV WB110MV
WB3_5V WB11MV WB330MV

Fluke 5700A Series II Specifications

General

Type	Multifunction Calibrator
Operating Temperature	0 °C to 50 °C
Storage Temperature	-20 °C to 70 °C
Voltage Range	0 to 1100 V
DC Voltage Range	10 μV to 1100 V
Frequency Range	1 MHz
Humidity	non-condensing
Power Requirements	100 V to 240 V
