Fluke 5700A Series II User Manual

5700A/5720A Series II
Operators Manual
A-14
2807 A11: ADC Amp Output Offset
2808 A11: ADC Amp Gain Error
2809 A11: DAC Monitoring Fault
2810 A11: +11V DC Range Fault
2811 A11: -11V DC Range Fault
2812 A11: +22V DC Range Fault
2813 A11: -22V DC Range Fault
2814 A11: 6.5V Buffered Reference Fault
2815 A11: 6.5V Reference Fault
2816 A11: 13V Buffered Reference Fault
2817 A11: 13V Reference Fault
2818 Assembly A11 Missing
2819 A11: 8255 Was Reset
2820 A11: Fine Adjust Channel Fault
2821 A8/A11: +11/22V DC Zero Estimate Fault
2822 A8/A11: -11/22V DC Zero Estimate Fault
2823 A11: Could not Estimate +11V Or 22V Gain
2824 A11: Could not Estimate 6.5V Or 13V Ref
2825 A11: Could not Estimate 6.5V Or 13V Buf Ref
2826 A11: A/D Overload Fault
3100-Level Faults: Self Diagnostics Subsystem (High Voltage)
3100 A14: 8255 Control Word
3101 A14: 8255 Port A Fault
3102 A14: 8255 Port B Fault
3103 A14: 8255 Port C Fault
3104 A15: HV Oven Regulation Fault
3105 A15: HV I Oven Regulation Fault
3106 A15: DC HV Amp Noise Fault
3107 A15: DC HV Amp Offset Fault
3108 A15: DC HV Amp Gain Fault
3109 A15: HV +DC Preamplifier Fault
3110 A15: HV +DC Series Pass & Current Fault
3111 A15: HV +DC High Voltage Output Fault

Fluke 5700A Series II Specifications

General

Type	Multifunction Calibrator
Operating Temperature	0 °C to 50 °C
Storage Temperature	-20 °C to 70 °C
Voltage Range	0 to 1100 V
DC Voltage Range	10 μV to 1100 V
Frequency Range	1 MHz
Humidity	non-condensing
Power Requirements	100 V to 240 V
