Fluke 5700A Series II User Manual

Appendices
Symbolic Names of Calibration Constants
C
C-9
R10 10Ω true value
R19 19Ω true value
R100 100Ω true value
R190 190Ω true value
R1K 1 kΩ true value
R1_9K 1.9 kΩ true value
R10K 10 kΩ true value
R19K 19 kΩ true value
Name Description
R100K 100 kΩ true value
R190K 190 kΩ true value
R1M 1 MΩ true value
R1_9M 1.9 MΩ true value
R10M 10 MΩ true value
R19M 19 MΩ true value
R100M 100 MΩ true value
RDIV10 Divider ratio Ohms Cal assembly to get 10V from 13V ref
RDIV5 Divider ratio Ohms Cal assembly to get 5V from 13V ref
RDIV2 Divider ratio Ohms Cal assembly to get 2V from 13V ref
RDIV_1 10k/90k divider on Ohms Cal assembly
ZERO_TEMP Recorded temperature for zero calibration
ALL_TEMP Recorded temperature main output calibration
G5205D 5205A gain, dc
G5205A 5205A gain, ac
G5220 5220A gain
W1G 1.1 mV wideband gain
W2G 3.3 mV wideband gain
W3G 11 mV wideband gain
W4G 33 mV wideband gain
W5G 110 mV wideband gain
W6G 330 mV wideband gain
W7G 1.1V wideband gain
W8G 3.5V wideband gain
WL1 Wideband thermal sensor correction constant #1

Fluke 5700A Series II Specifications

General

Type	Multifunction Calibrator
Operating Temperature	0 °C to 50 °C
Storage Temperature	-20 °C to 70 °C
Voltage Range	0 to 1100 V
DC Voltage Range	10 μV to 1100 V
Frequency Range	1 MHz
Humidity	non-condensing
Power Requirements	100 V to 240 V
