Fluke 5700A Series II User Manual

5700A/5720A Series II
Operators Manual
C-10
WL2 Wideband thermal sensor correction constant #2
WL3 Wideband thermal sensor buffer offset
WBAND_TEMP Recorded temperature for wideband gains calibration
WF1 No attenuators wideband flatness correction, 1 kHz
WF2 Same, 12 kHz
WF3 Same, 100 kHz
WF4 Same, 500 kHz
WF5 Same, 1.1999 MHz
WF6 Same, 1.2 MHz
Name Description
WF7 Same, 2 MHz
WF8 Same, 10 MHz
WF9 No attenuators wideband flatness correction, 20 MHz
WFA Same, 30 MHz
WFB Spare
WFC Spare
W1F1 10 dB attenuator wideband flatness correction, 1 kHz
W1F2 Same, 12 kHz
W1F3 Same, 100 kHz
W1F4 Same, 500 kHz
W1F5 Same, 1.1999 MHz
W1F6 Same, 1.2 MHz
W1F7 Same, 2 MHz
W1F8 Same, 10 MHz
W1F9 Same, 20 MHz
W1FA Same, 30 MHz
W1FB Spare
W1FC Spare
W2F1 20 dB attenuator wideband flatness correction, 1 kHz
W2F2 Same, 12 kHz
W2F3 Same, 100 kHz
W2F4 Same, 500 kHz
W2F5 Same, 1.1999 MHz
W2F6 Same, 1.2 MHz
