Fluke 5700A Series II User Manual

Appendices
Symbolic Names of Calibration Constants
C
C-11
W2F7 Same, 2 MHz
W2F8 Same, 10 MHz
W2F9 Same, 20 MHz
W2FA Same, 30 MHz
W2FB Spare
W2FC Spare
W3F1 10 dB and 20 dB together wideband rf correction, 1 kHz
W3F2 Same, 10 MHz
W3F3 Same, 20 MHz
W3F4 Same, 30 MHz
Name Description
W3F5 Spare
W3F6 Spare
W4F1 40 dB attenuator wideband flatness correction, 1 kHz
W4F2 Same, 12 kHz
W4F3 Same, 100 kHz
W4F4 Same, 500 kHz
W4F5 Same, 1.1999 MHz
W4F6 Same, 1.2 MHz
W4F7 Same, 2 MHz
W4F8 Same, 10 MHz
W4F9 Same, 20 MHz
W4FA Same, 30 MHz
W4FB Spare
W4FC Spare
W5F1 10 dB and 40 dB together wideband rf correction, 1 kHz
W5F2 Same, 10 MHz
W5F3 Same, 20 MHz
W5F4 Same, 30 MHz
W5F5 Spare
W5F6 Spare
WB_FLAT_TEMP Recorded temperature for wideband flatness calibration
TW1 Manual range adjust, 220 mV dc
TW2 Manual range adjust, 2.2V dc

Fluke 5700A Series II Specifications

General

Type	Multifunction Calibrator
Operating Temperature	0 °C to 50 °C
Storage Temperature	-20 °C to 70 °C
Voltage Range	0 to 1100 V
DC Voltage Range	10 μV to 1100 V
Frequency Range	1 MHz
Humidity	non-condensing
Power Requirements	100 V to 240 V
