Physical Features
21
eih31f.eps
Figure 2. EtherScope Network Assistant’s Physical Features
Fan
Stand
Removeable
Battery Pack
Power
Jack
USB Port
Microphone
Jack
Headphone
Jack
Fiber LAN Connector
RJ45 LAN Connector
Kensington
Lock
(left side)
DB9 Serial Port
Strap Attach
Stylus
Compact Flash SLOT 2
PCMCIA/CardBus SLOT 1
