FOR-A FA -10DCCRU - Page 41

41
④ Out Color Space
Setting range: Rec. 709, Rec. 2020
Default (UNITY): Rec. 709
⑤ ST 2084 (PQ) Range
Setting range: 1 - 64%
Default (UNITY): 64%
Button
Setting
Level indicators
Panel display
VIDEO
LEVEL
A
Lit orange.
Flashes at 64%.
64%
C
Lit orange.
Flashes at 1%.
1% - 63%
⑥ Dynamic Range
Setting range: 0.5 - 65%
Default (UNITY): Changes depending on the EOTF setting (②)
Button
Setting
Level indicators
Panel display
VIDEO
LEVEL
A
Lit orange.
Flashes at 65%.
(Variable) - 65%
B
Lit green (UNITY)
(Variable)
C
Lit orange.
Flashes at 0.5%.
0.5% - (Variable)
⑦ Gamma Range
Setting range: 25 - 100%
Default (UNITY): 100%
Button
Setting
Level indicators
Panel display
VIDEO
LEVEL
A
Lit orange.
Flashes at 100%.
100%
C
Lit orange.
Flashes at 0.5%.
25% - 100%
IMPORTANT
Note that changes are applied to all linked FS channels (FS Link On) in an FA-505,
FA-1010 or FA-9520 (FA-9520 mode). See section 11. “FS Link” for more details.
