43
6-11-2-3. Color Space
The Color Space menu is supported in FA-505 Software Version 2.00 and later.
With the Color Space menu displayed, pressing + (and with FS SEL unlit) displays the
following settings.
EOTF→Input Color Space→OETF→Output Color Space
→Dynamic Range→Gamma Range→ST 2084 (PQ) Range
* Pressing the - button displays settings in the reverse order.
Repeatedly pressing the + (or - ) button displays settings one after another. When
the end setting is reached, the display returns to the top item. If the control is turned
while displaying settings using the + button, the changed setting is displayed.
Pressing the + button after that displays the next setting of the setting displayed
before the control is turned.
Example: Pressing the + button and adjusting SETUP/BLACK while Y LEVEL (YL
100%) is displayed shows “SB 10%”. Pressing the + button after that displays “Hue
0 ﾟ.”
The - button works in the same way but in the reverse direction.
