9-9. Messages during Video Clip Settings
In Full display mode, text in parentheses are displayed during menu settings.
When verifying settings using － and ＋ buttons, information is displayed in Simple display
mode.
See section 6-10. “Clipping Signal Levels” for more details.
 When FA-505 Software Version is 2.00 and later:
Displayed message
(Full)
Displayed message
(Simple)
When information/message is displayed:
Clip Off
(Same as in Full mode)
Displayed when Video Clip Mode is set to
Off.
RGB Clip
(Same as in Full mode)
Displayed when Video Clip Mode is set to
RGB.
YPbPr Clip
(YPbPr)
YpbPr
Displayed when Video Clip Mode is set to
YPbPr.
RGB White Clip: ***.*%
(***.*％)
RW ***%
Displayed when the RGB White Clip Level
setting is changed.
RGB Black Clip: ***.*%
(***.*％)
RB ***%
Displayed when the RGB Black Clip Level
setting is changed.
White Knee Point: ***.*
(****.*％)
WKP***%
Displayed when the White Knee Point
setting is changed.
White Knee Slope: **
WKS **
Displayed when the White Knee Slope
setting is changed.
Black Knee Point: ***.*
(***.*％)
BKP ***%
Displayed when the Black Knee Point
setting is changed.
Black Knee Slope: **
BKS **
Displayed when the Black Knee Slope
setting is changed.
Y White Clip: ***.*%
(***.*％)
YW ***%
Displayed when the Y White Clip Level
setting is changed in YPbPr mode.
Y Black Clip: ***.*%
(***.*％)
YB ***%
Displayed when the Y Black Clip Level
setting is changed in YPbPr mode.
Chroma Clip: ***.*%
(***.*％)
CW ***%
Displayed when the Chroma Clip Level
setting is changed in YPbPr mode.
Input Color Space:
*******
(Same as in Full mode)
Displayed when the Input Color Space
setting is changed.
EOTF: *******
(Same as in Full mode)
Displayed when the EOTF setting is
changed.
Output Color Space:
******
(Same as in Full mode)
Displayed when the Output Color Space
setting is changed.
OETF: *******
(Same as in Full mode)
Displayed when the OETF setting is
changed.
PQ Range: ****.*%
PQ **%
Displayed when the ST2084 (PQ) Range
setting is changed.
Dynamic Range: **.*%
DR **%
Displayed when the Dynamic Range setting
is changed.
Gamma Range: ***.*%
GRng ***%
Displayed when the Gamma Range setting
is changed.
The display is automatically turned off when there is no operation within 1 minute.
 When FA-505 Software Version is 1.21 and earlier
Displayed message
(Full)
Displayed message
(Simple)
When information/message is displayed:
Clip Off
(Same as in Full mode)
Displayed when Video Clip Mode is set to
Off.
