10-2-3. GPI Input Settings
A combination of GPI input settings (Setting 1, Setting 2 and Setting 3) can be assigned to
each GPI port.
GPI ports are activated when they are closed with a common port.
(1) First, set Setting 1. To disable ports, set None under Setting 1.
Detailed Input Settings
Setting 1 setting
Description
Refer to
None
No function
-
MU Select
MU Select allows you to select a main unit under Setting 2 (Unit
ID1 - 100) and an FS of the main unit under Setting 3 (FS1 - 10).
If set to None under Setting 3, the last controlled FS is selected.
Main unit IP addresses must be set for Unit ID numbers in
advance.
If set to Disconnect under Setting 2, the port can disconnect
main units.
5-3-4
FS Select
FS Select allows you to select an FS under Setting 2, FS1 - FS10
if connecting to FS-1010 and FS1 or FS2 if connecting to FA
-9520 (FA-9520 mode).
FS Select is inoperative when connecting with FA-9520 (FA-9500
mode) or FA-9500 units.
-
FS Link
(toggled On/Off)
Allows you to link or unlink an FS under Setting 2.
If All Clear is set under Setting 2, all FS channels are unlinked.
11
Freeze
(toggled On/Off)
Allows you to set Freeze to On or Off.
If an FS is selected under Setting 2, the controlled FS is changed
to the selected one and a Freeze setting is applied to it.
If None is set under Setting 2, a Freeze setting applies to the
current FS.
6-4
Split Mode
Allows you to set Split mode under Setting 2.
If an FS is selected under Setting 3, the controlled FS is changed
to the selected one and a Split Mode setting is applied to it.
If None is set under Setting 3, a Split Mode setting applies to the
current FS.
6-5
CC Mode
Allows you to set Color Correction mode under Setting 2.
If an FS is selected under Setting 3, the controlled FS is changed
to the selected one and a CC Mode setting is applied to it.
If None is set under Setting 3, a CC Mode setting applies to the
current FS.
6-9
Gamma Curve
Allows you to set Gamma Curve under Setting 2.
If an FS is selected under Setting 3, the controlled FS is changed
to the selected one and a Gamma Curve setting is applied to it.
If None is set under Setting 3, a Gamma Curve setting applies to
the current FS.
6-9
Clip
(When FA-505 Software Version is 2.00 or later)
Allows you to select Clip mode.
Off: Turns Off YPbPr Clip and opens the YPbPr Clip setting
menu.
YPbPr Clip: Turns On YPbPr Clip and opens the YPbPr Clip
setting menu.
RGB Clip: Opens the RGB Clip setting menu.
(When FA-505 Software Version is 1.10 or earlier)
Allows you to set Clip mode under Setting 2.
If an FS is selected under Setting 3, the controlled FS is changed
to the selected one and a Clip setting is applied to it.
If None is set under Setting 3, a Clip setting applies to the current
FS.
6-10
GPI Lock
(toggled On/Off)
Allows you to enable (GPI Lock Off) / disable (GPI Lock On) all
GPI inputs.
-
