8-2. GPI OUT LED Indicator Brightness Settings
GPI OUT No.
Controller
System menu item
(GPI connector)
FA-AUX30
block
GPI- OUT 1
VIDEO LEVEL
⑦ GPI1 No.1-10
(GPI1)
Left block
GPI- OUT 2
Y LEVEL
GPI- OUT 3
C LEVEL
GPI- OUT 4
SETUP/BLACK
GPI- OUT 5
HUE
GPI- OUT 6
WHITE LEVEL R
GPI- OUT 7
WHITE LEVEL G
GPI- OUT 8
WHITE LEVEL B
GPI- OUT 9
BLACK LEVEL R
GPI- OUT 10
BLACK LEVEL G
GPI- OUT 11
VIDEO LEVEL
⑧ GPI2 No.11-20
(GPI2)
Center block
GPI- OUT 12
Y LEVEL
GPI- OUT 13
C LEVEL
GPI- OUT 14
SETUP/BLACK
GPI- OUT 15
HUE
GPI- OUT 16
WHITE LEVEL R
GPI- OUT 17
WHITE LEVEL G
GPI- OUT 18
WHITE LEVEL B
GPI- OUT 19
BLACK LEVEL R
GPI- OUT 20
BLACK LEVEL G
GPI- OUT 21
VIDEO LEVEL
⑨ GPI3No.21-30
(GPI3)
Right block
GPI- OUT 21
Y LEVEL
GPI- OUT 23
C LEVEL
GPI- OUT 24
SETUP/BLACK
GPI- OUT 25
HUE
GPI- OUT 26
WHITE LEVEL R
GPI- OUT 27
WHITE LEVEL G
GPI- OUT 28
WHITE LEVEL B
GPI- OUT 29
BLACK LEVEL R
GPI- OUT 30
BLACK LEVEL G
* See section 10-4. “GPI1-GPI3 Pin Assignments.“
