FOR-A FA -10DCCRU - 13 Specifications and Dimensions; Unit Specifications; External Dimensions

72
13. Specifications and Dimensions
13-1. Unit Specifications
Interfaces
TO MU
10/100/1000 BASE-T, RJ-45 x 1 port
GPI
25-pin D-sub (female) x 3, 30 inputs and 30 outputs
Temperature
0ºC to 40ºC
Humidity
30% to 90% (no condensation)
Power
100V - 240V AC ±10%, 50/60Hz
Power Consumption
21VA (11W) (at 100 V AC)
24VA (11W) (at 200 V AC)
Dimensions
430 (W) x 44 (H) x 140 (D) mm
Weight
2.4 kg
Consumables
Power supply unit: Replace every 5 years
Cooling fan: P1467-1, replace every 5 years
Accessories
Operation Manual (CD-ROM) , AC cord, Rack mount brackets
13-2. External Dimensions
(All dimensions in mm.)
480
462
430
40 350 40
4
4
3
2
6
6
6
.
4
3
0
.
5
8
9
.
5
2
0
3
3
1
4
0
2
.
3
1-5 6-10
11-15/UNIT 16-20
BYPS/OP FS SEL
MEMORY/SET
0 1 2 3 4 5 6 7
FREEZE
CLIP
SPLIT
SELECT - +
SAVE LOAD CLEAR
VIDEO LEVEL Y LEVEL C LEVEL HUE
UNITY UNITY UNITY UNITY UNITY
SYSTEM
GRP ADJ
UNITY UNITY UNITY UNITY UNITY UNITY
R G B R G B
WHITE LEVEL BLACK LEVEL
UNITY UNITY UNITY
R G B
GAMMA
WHITE BAL
FA-10DCCRU
CENTER DIF
BLACK SEPIA
T O M U
( 1 0 / 1 0 0 / 1 0 0 0 B A S E - T )
G P I 1 G P I 2 G P I 3
P O W E R
A
C
1
0
0
-
2
4
0
V
5
0
/
6
0
H
z
I
N
O F F
O N
PROCESS CONTROL
SETUP/BLACK
