11. FS Link
The FS Link function allows you to simultaneously apply the same settings (Proc Amp, Color
Correction and Clip) to all linked FS channels in FA-505, FA-1010 or FA-9520 (FA-9520 mode).
This function is available only when FS links are enabled. FS link settings can be performed by GPI
inputs sent from an FS-AUX30 or other GPI device/s to the FA-10DCCRU.
11-1. Requirements for FS Link
1. The same Color Correction mode is set in linked FS channels.
2. The same Clip mode is set in linked FS channels.
FS channels cannot be linked if the above two requirements are not met.
In addition, Color Correction and Clip modes cannot be changed in FS-linked channels.
To change these modes, set FS link to off.
11-2. Notes on FS Link
An FA-10DCCRU always selects and controls an FS when connecting an FA-505, FA-1010 or
FA-9520 (FA-9520 mode).
If the FS is not linked, settings are applied only to the FS.
If the FS is linked, settings are applied simultaneously to all linked FS channels.
* FS links can be set only by GPI inputs sent from GPI devices such as an FA-AUX30.
* Refer to section 10-2-3. “GPI Input Settings” for details on how to assign the FS Link function
to GPI inputs.
* Refer to section 16-9. “Color Correction” for details on Color Correction mode.
* Refer to section 6-10. “Clipping Signal Levels” for details on Clip mode.
* Refer to section 6-3. “Selecting an FS Channel” for details on FS selection.
To prevent unexpected operational errors, assigning “FS Select” functions to GPI inputs is
recommended.
11-3. FS Link Examples
Assume that the main unit is FA-1010 and that FS1 - FS10 are set as shown below.
Color Correction mode is set to Balance in FS1 - FS8.
Clip mode is set to Off in FS1 - FS8.
FS1 - FS5 are linked On. FS6 - FS10 are linked Off. (See the figure below.)
Color Correction mode is set to Differential in FS9.
Clip mode is set to RGB in FS10.
