8-1. System Settings
No.
Menu item
Setting buttons
Description
①
Unity Mode
－, ＋ buttons
－ Unlinked:
UNITY is applied only to the relevant FS channel.
＋ Linked:
UNITY is applied to all linked FS channels.
See section 11. “FS Link” for more details.
②
Front Buzzer
－, ＋ buttons
－ Disable: Disables the front buzzer.
＋ Enable: Enables the front buzzer.
③
GPI Buzzer
－, ＋ buttons
－ Disable: Disables the buzzer for GPI settings.
＋ Enable: Disables the buzzer for GPI settings.
④
Display Mode
－, ＋ buttons
－ Full: Displays settings in detailed format.
＋ Simple: Displays settings in short format.
⑤
Display BRIGHT
－, ＋ buttons
Sets front panel brightness.
Options are 1.7%, 3.3%, 5%, 6.7%, 8.3%, 11.7%, 15%,
18%, 23%, 30%(default), 37%, 47%, 60%, 80% and100%
⑥
GPI1 No.1-10
Rotary encoder
(*1)
Sets brightness for GPI OUT LED indicators (No1 – 10)
from 0 to 255. (Default: 50)
⑦
GPI2 No.11-20
Rotary encoder
(*1)
Sets brightness for GPI OUT LED indicators (No11 – 20)
from 0 to 255. (Default: 50)
⑧
GPI3 No.21-30
Rotary encoder
(*1)
Sets brightness for GPI OUT LED indicators (No21 – 30)
from 0 to 255. (Default: 50)
⑨
IP: 192.168.0.101
(Display only)
Displays the FA-10DCCRU IP address.
⑩
Subnet 255.255.255.0
(Display only)
Displays the FA-10DCCRU subnet mask.
⑪
Gateway 0.0.0.0
(Display only)
Displays the FA-10DCCRU default gateway.
⑫
FAN
(*2)
(Display only)
Displays the FA-10DCCRU fan status.
Normal: The fan is functioning normally.
Stopped: The fan has stopped.
⑬
Software Ver: 2.00
(Display only)
Displays the software version.
⑭
FPGA1 Ver: 1.00
(Display only)
Displays the FPGA1 version.
⑮
FPGA2 Ver: 1.00
(Display only)
Displays the FPGA2 version.
(*1) See section 8-2. “GPI OUT LED Indicator Brightness Settings.”
(*2) When the fan has stopped, turn off the unit power, notify your FOR-A reseller or supplier and change the
fan.
