10-3. GPI Pattern List
The following available GPI patterns are mainly for FA-AUX30 use.
Buttons and their functions shown in each pattern represent a button block of FA-AUX30 units.
 MU Select
Button function
Description
MU ID1 - 10
Used for MU selection by specifying ID1 – ID10.
The LED lights while an MU is connected.
 FS Select
Button function
Description
FS1 - 10
Used for FS selection from FS1 - FS10.
The LED lights while an FS is being controlled.
 FS Link Select
Button function
Description
FS1 – 10
Link
Used to enable FS Link. The LED lights while an FS is linked.
When the FS cannot be linked, an error beep sounds.
MU
ID1
MU
ID2
MU
ID3
MU
ID4
MU
ID5
MU
ID6
MU
ID7
MU
ID8
MU
ID9
MU
ID10
FS1
FS2
FS3
FS4
FS5
FS6
FS7
FS8
FS9
FS10
FS1
Link
FS2
Link
FS3
Link
FS4
Link
FS5
Link
FS6
Link
FS7
Link
FS8
Link
FS9
Link
FS10
Link
