10-5. GPI Input Circuit
10-6. GPI Input Control
 Pulse signals
The pulse signal level change (OPEN to CLOSE) triggers each operation.
OPEN to CLOSE: The assigned function will be turned on.
OPEN
CLOSE
100msec or more
PIN 1, 7, 19
PINs 8~12 20~24 (IN)
FA-1010 inside
